Split unit air conditioner
S 5232
Split unit air-conditioner
Cooling function
Comfortable heat
Dehumidifier function
Description
All benefits
- Split unit air-conditioner
- Cooling function
- Comfortable heat
- Dehumidifier function
- Energy efficient
- Smart connect
- Sleep mode
- Timer function
- Very silent
Specifications
Product name Split unit air conditioner S 5232 white
EAN code 8713508781334
Model S 5232
Colour White
Product type Split unit air conditioner
Warranty compressor 4
EAN indoor unit 8713508781075
EAN outdoor unit 8713508781082
Net. weight - indoor unit 8.2
Net. weight - outdoor unit 27
Airflow - low/mid/high - cooling 294 / 478 / 539
Airflow - low/mid/high - heating 294 / 478 / 539
Indicative annual electricity consumption during cooling season (Qce) 175
Indicative annual electricity consumption during average heating season (Qhe) 922
SCOP ratio 4.1
SEER ratio 7
Energy class A++ / A+
Refrigerant - type R32
Start. length refr. pipe between in- / outdoor unit 4
Wifi ready Yes
Heating capacity - pdesignh 2.7
Cooling capacity - pdesignc 3.5
Timer function Yes
Quick connector No
Defrost function No
Sleep mode Yes
Rated power cooling (min.) 0.82
Rated power cooling 3.5
Rated power heating (min.) 0.85
Rated power heating 2.7
Fan speeds 4
Included filters Active carbon, HAF, Screen
Thermostatic range (max.) 30
Thermostatic range (min.) 17
Included - remote control Yes
Sound power level (SWL) 56
Cooling mode Yes
Dehumidifying mode Yes
Heating mode Yes
Thermostatic range 17~30
Apps available Yes
Air outlet - position bottom
Timer setting (max.) 24
Heating capacity steps 2 (850 / 4770 W)
Heating capacity (max.) 4.777
Heating capacity (min.) 0.85
Ductable not ductable
Heating capacity (max.) - in Watt 4770
Heating capacity (min.) - in Watt 850
SEER / SCOP 7 / 4,1
Airflow - high mode - heating 539
Amount of air ducts 0
Airco function Reversible
Energy consumption - stand-by mode 1
For rooms up to 80 - 100
For areas up to 32 - 40
Width - indoor unit 802
Depth - indoor unit 189
Height - indoor unit 297
Width - outdoor unit 770
Depth - outdoor unit 300
Height - outdoor unit 555
