Monoblock airco cooling and heating WDH 229 PTC

Monoblock airco cooling and heating

WDH 229 PTC

No outer unit

No outer unit

R290 Eco-friendly refrigerant

R290 Eco-friendly refrigerant

Cooling function

Cooling function

Comfortable heat

Comfortable heat

Monoblock airco cooling and heating WDH 229 PTC white

Product information

Cool, warm, easy: comfort all year round without an outdoor unit!

Your bedroom or workplace quickly cooled in summer with an air conditioner without an outdoor unit. Energy-saving additional heating on colder days. No installer needed. The advantages of the Monoblock WDH 229 Air conditioning without an outdoor unit Energy-saving additional heating with the heat pump Easily cools a 25 m2/6 m3* room Also works as a dehumidifier and air purifier Can be mounted without an installer ¨ No hassle with a drain hose from the window * This is an indication of the surface area. We have assumed homes with an average ceiling height.
house Find a store
Trustpilot

Description

In your home, you spend a lot of time. In recent years, even more than usual. So it is important that the place where you work or sleep is both comfortable and healthy. Not too hot, not too cold. And clean air that helps you focus. Or sleep, of course. Control the perfect temperature for your bedroom or study or hobby room with the Qlima Monoblock WDH229. One system for cold, warm and filtered air Qlima Monoblock WDH 229 is not an 'ordinary air conditioner'. It is an air conditioning system. That means you can always influence the room temperature all year round. On sunny summer days, this air conditioning unit provides cooling in no time. On colder spring or autumn days, you make it cosily warm by using the heat pump extra. This eliminates the need to turn up the heating a few degrees. Don't think of it as main heating, because the Monoblock is not made for really harsh winter weather, its heating capacity is no match for that. Healthy for you and your home When you have the Monoblock on cooling mode, the air is also automatically ventilated, dehumidified and cleaned. This is good for your own health, but also for that of the room itself. Not ventilating properly is more likely to cause dampness and mould. In a ventilated house, these don't have a chance. Is the WDH229 Monoblock Air Conditioner right for you? For whom: anyone with an owner-occupied house (because it requires drilling) What is it: an 'air conditioning heater', consisting of one unit for indoor use. It quickly brings down the temperature of a room and is the perfect auxiliary heating in spring or autumn. Cooling: easily covers an entire 25m2* room Heating: the same room a few degrees warmer in no time Installation: You can do it yourself. Maybe with some help, but you can save the costs of an installer. Good to know: the heating function is not meant to heat your whole house, especially on days of harsh winter weather. Heating larger rooms in your home? Then our pellet stoves might be an idea. * This is an indication of the minimum surface area. For example, we assume that the room to be cooled has the average Dutch height. If your ceilings are lower, the Monoblock will cool a larger surface area. Read also: cooling capacities explained. An air conditioner or a heat pump? Most people will say "I bought a great airco now!" when talking about the Qlima WDH229 Monoblock. Airco is front of mind, as the cooling function is the most commonly used. But technically, it is a heat pump. That's what we call all air-conditioned systems that can cool as well as heat. The Qlima WDH229 Monoblock Air Conditioner has two separate airflows, completely separated from each other. One draws cooling air from outside. Heat from inside is removed to the outside. When it gets colder, you easily reverse that process. The refrigerant then flows in the other direction. In that case, the heat pump extracts heat from the outside air and blows the warm air inside.

All benefits

  • check No outer unit
  • check R290 Eco-friendly refrigerant
  • check Cooling function
  • check Comfortable heat
  • check Dehumidifier function
  • check Inverter techology
  • check Ultra silent mode
  • check Smart connect
  • check Adjustable fan speed
  • check Monoblock heatpump

Specifications

Colour White

Country of production China

Model WDH 229 PTC

Warranty 2 years

EAN code 8713508792811

Adjustable air flow - horizontal Yes

Airco function Reversible

Air duct Yes

Airflow - high mode 520 m³/h

Control Electronic, Remote control, Wi-Fi

COP class A

COP ratio 3.1 W/W

Defrost function Yes

Dehumidifying capacity at 27°c / 60% RH 21.6 l/24 h

Dehumidifying capacity at 32°c / 80% RH 48 l/24 h

Dehumidifying mode Yes

Diameter air duct 180 mm

Ductable double

Economic mode Yes

EER class A

EER ratio 2.6 W/W

Energy consumption - stand-by mode 1.3 Wh

Fan mode Yes

Fan speeds 3 positions

For rooms up to 60 - 85 m³

Included - remote control Yes

Number of timer settings 24

Operating range temperature -7~35 °C

Protection class IPX0 IPxx

Rated current cooling 5 A

Rated power cooling (max.) 3.52 kW

Rated power cooling (min.) 1 kW

Rated power heating (max.) 3.52 kW

Rated power heating (min.) 0.7 kW

Refrigerant type / GWP / Charge R290 / 3 / 290 R/g

Smart Tuya

Sound power level (SWL) 58 dB

Thermostatic range 16~30 °C

Timer function Yes

Turbo function Yes

Dimensions (w x d x h) 1000 x 205 x 585 mm

Dimensions package (w x d x h) 112 x 34 x 66 cm

Weight - unit 43 kg

Gross weight 49 kg

Manuals and documentation

Product Reviews

Spare parts

SpareArticles (16) chevron-down

EAN Name
8713508786889 Air filter MBACCV101910
8713508004686 Air grill set MBACCV103554
8713508787220 Display board MBACCV101954
8713508793085 Electronic expansion valve MBACCV102699
8713508793092 Fan MBACCV102700
8713508795034 Fan assembly MBACCV102852
8713508787312 Indoor evaporator motor MBACCV101992
8713508793108 Mainboard MBACCV102701
8713508793061 Outdoor condenser motor and fan MBACCV102697
8713508793115 Remote control MBACCV102702
8713508004693 Sealing strip MBACCV103555
8713508787336 Splashwheel motor MBACCV101994
8713508786940 Stepper motor MBACCV101919
8713508793122 Variable frequency drive plate MBACCV102703
8713508004709 Wall duct 450x600mm
8713508793139 Wi-Fi board MBACCV102704
Features and Benefits

Features and Benefits

  • Dehumidifier function Dehumidifier function
  • Inverter techology Inverter techology
  • Ultra silent mode Ultra silent mode
  • Smart connect Smart connect
  • Adjustable fan speed Adjustable fan speed
  • Monoblock heatpump Monoblock heatpump
